SYSTEM FOOTPRINT
DIMENSIONS L X W X H inches (mm)
- 48” x 33” x 56” (1219mm x 838mm x 1422mm)
WEIGHT pounds (kg)
- 800 lb (363 kg)
OPTIONAL ACCESSORIES
- BAUER CONNECT® secure VPN IoT – allows remote monitoring by customer and customer’s chosen BAUER authorized service provider to tailor maintenance cycles based on compressor usage as well as monitor compressor alarms and faults for faster service response
STANDARD SCOPE OF SUPPLY
- BAUER P2/P5 air purification system with B-SECURUS (Electronic moisture monitoring)
- Fully integrated BAUER engineered CO monitoring system
- BAUER’S patented zero loss automatic condensate drain system
- Open vertical design in place of cabinet made of formed sheet and plate goods provides a firm foundation for all pressure bearing components
- Modern design with unsurpassed maintenance accessibility (no hand tools are required for normal maintenance checks and fluid level confirmation)
- BAUER B-CONTROL HMI touchscreen display
- NEMA 4 rated electrical enclosure with UL® listed control panel
- All wiring harnesses incorporated within a corrugated loom with number coding for easy system diagnosis
- Emergency stop push button
- Compressor final pressure, oil pressure and high-temperature monitoring
- Motor overload indication
- Final separator counter with shutdown and operator indication
- Interstage pressure gauges (locally mounted)
- Heavy duty .049 wall thickness stainless steel tubing throughout
- Rugged powder coat finish
- Unique integrated positioning base which ensures correct installation every time
TECHNICAL DATA
| Model | Charging Rate1 | Number of Stages | Motor | FAD2 | RPM | Purification System | ||
|---|---|---|---|---|---|---|---|---|
| SCFM | l/min | HP | kW | |||||
| 6000 PSIG (414 BAR) | ||||||||
| VERTECON SE 8-E1 | 8.4 | 237 | 3 | 7.5 | 5.6 | 7.5 | 1350 | P2 B-SECURUS |
| VERTECON SE 8-E3 | 8.4 | 237 | 3 | 7.5 | 5.6 | 7.5 | 1350 | P2 B-SECURUS |
| VERTECON SE 13-E1 | 13 | 368 | 4 | 10 | 7.5 | 10.8 | 1420 | P2 B-SECURUS |
| VERTECON SE 13-E3 | 13 | 368 | 4 | 10 | 7.5 | 10.8 | 1420 | P2 B-SECURUS |
| VERTECON SE 18-E3 | 18 | 510 | 4 | 15 | 11 | 15 | 1325 | P5 B-SECURUS |
1) Based on recharging an 80 cubic foot tank from 500 to 3000 psig.
2) Compressor capacity referenced to standard inlet conditions.
E1= Single phase electric, 230 VAC/60 Hz
E3=Three phase electric, 208 VAC/60 Hz
Dimensions and weight are approximate and are subject to change.
