BAUER offers two models of these high-performance compressor systems.
- The BAUER BAUER GRU® XL System: Capable of evacuating a 36-inch, 20-mile pipeline from 100 psig down to zero psig in 6 days, 18 hrs.
- The BAUER BAUER GRU® XXL System: Capable of blowing down a 36-inch, 20-mile pipeline down from 100 psig to zero psig in 3 days, 11 hrs.
BAUER GRU® XL AND XXL SYSTEM OPERATION
Most reciprocating booster compressors which are currently used for pipeline blow-down and re-injection are designed to operate efficiently at their optimal flow between a suction pressure range of 100 to 250 psig. As efficient as these systems are at high inlet pressures (suction pressure into the compressor), their performance declines exponentially as the pipeline residual pressure drops to below 100 psig.
The BAUER GRU® Rotary Screw Blow-down Compressor System is designed to efficiently take pipeline residual pressure from 100 psig down to 0 – 5 psig while feeding High-Pressure Reciprocating Booster Compressors at their optimal suction pressure to maintain their maximum flow performance. This allows the pipeline blowdown operator to not only take residual pipeline pressure close to zero to meet their customers’ ESG requirements but to also significantly reduce blow down time in order to satisfy their customers’ tight time-line requirements.
- The secret behind the BAUER GRU®‘s exceptional performance at low suction pressures is BAUER’s rotary screw gas compressor technology which allows the compressor to work efficiently at very low inlet (compressor suction) pressures.
- The BAUER GRU® systems are electric drive via VFD so that the speed of the compressor can be precisely modulated based on inlet and outlet conditions. This function is fully automatic. The systems adjust motor speed based on the desired outlet pressure settings and available inlet (suction pressure) during the blowdown process.
- In mobile field applications, the electric drive BAUER GRU® blowdown compressor systems can be powered by a standard mobile Natural Gas generator set.
1 x BAUER GRU® Duplex System:
- BAUER GRU® XL: 2 x 250 HP TEFC motors (500 HP combined)
- BAUER GRU® XXL: 2 x 350 HP TEFC motor (700 HP combined)
- Hazardous area classification: Class 1, Div II.
- The BAUER GRU® XL duplex compressor system is built in a 40-foot custom-built ISO container with an integrated gas-tight electrical room, which houses the VFDs.
- The BAUER GRU® XXL duplex is built in a 40-foot custom-built ISO container. Due to the size of the system, the electric motor VFDs are off-skid.
- The BAUER GRU® XL and XXL compressor systems are built for mobility and can be mounted and operated on top of a standard 40-foot trailer chassis.
- All systems are equipped with inlet and outlet gas flanges at the skid edge for ease and expediency in making the gas connections to the system.
- For remote field operation, a separate mobile generator set is required to operate the BAUER GRU® systems. All systems are equipped with a handshake relay for generator power.
- 2-Years parts and labor backed by BAUER’s lifetime support warranty.
BAUER CONNECT® IOT
All BAUER GRU® systems are equipped with BAUER CONNECT® IOT/Remote Telemetry.
This includes the following functionalities:
- Remote operation of the equipment through our Remote HMI feature.
- Remote monitoring of the equipment.
- SCADA systems which present a dynamic visual overview of the system.
- Historical reporting of critical performance parameters customizable per customer wishes.
- Text and e-mail notifications
- Predictive analytics
