SYSTEM FOOTPRINT

DIMENSIONS L X W X H inches (mm)

  • 48” x 32” x 28” (1219mm x 819mm x 711mm)*

WEIGHT pounds (kg)

  • 300 - 450 lb (136 - 204 kg)

* Base Model

AVAILABLE ACCESSORIES (Factory Installed)

  • B-Timer (P-31)

AVAILABLE ACCESSORIES

(Dealer/Customer Installed)

  • Riser Kit
  • Wheel kit

STANDARD SCOPE OF SUPPLY

Available in three sizes 8,10 &13 SCFM charge rate

  1.    Choice of prime mover/drive
  2.    Electric motor, 1-phase or 3-phase
  3.    Gasoline engine (pull start)
  4.    Diesel engine (DMTII 08-DY & DMTII 10-DY, EPA Tier 4 Final, Pull start)
  •  Inlet filter
  •  Stainless steel intercoolers and aftercooler
  •  High-temperature switch (except D drive)
  • Vibration isolators
  • P31 Purification for 5000 PSIG systems
  • P41 Purification for 6000 PSIG systems
  • Low oil pressure switch (electric drive)
  • Motor starter with NEMA 4 enclosure (electric drive units)
  • Hourmeter (electric and gasoline drive) or Vibration type (diesel drive)
  • Final pressure switch (electric & gasoline drive)
  • Visual CO/moisture indicator
  • Tubular aluminum frame

DMT II  ELITE (ADD to ABOVE)

  • Interstage gauges
  • Automatic condensate drain
  • Electric start and low oil pressure switch for gasoline and diesel drive units.

TECHNICAL DATA

Model Charging Rate1 Number of Stages Motor FAD2 Purification System
  scfm l/min   HP kW
5000 PSIG (345 BAR)
DMTII 08-E1/E3 8.4 238 3 7.5 5.6 7 P31
DMTII 08-GK 8.4 238 3 14 10.4 7 P31
DMTII 08-DY 8.4 238 3 8.3 6.2 7 P31
 6000 PSIG (414 BAR)
DMTII 10-E1/E3 9.7 275 4 7.5 5.6 8.1 P41
DMTII 10-GK 9.7 275 4 14 10.4 8.1 P41
DMTII 10-DH 9.7 275 4 8.3 6.2 8.1 P41
DMTII 13-E1/E3 13 368 4 10 7.5 10.8 P41
DMTII 13-GK 13 368 4 10 10.4 10.8 P41
DMTII 13-DH 13 368 4 14 10.4 10.8 P41

1) Based on recharging an 80 cubic foot tank from 500 to 3000 psig
2) Compressor capacity referenced to standard inlet conditions

E1= Single phase electric, 230 VAC/60 Hz
E3 = Three-phase electric, 208/230/460 VAC/60 Hz.
Other voltages available on request

GK = Gasoline engine drive, KOHLER
DH = Diesel engine drive, HATZ

Dimensions and weight are approximate and are subject to change
